| CPU |
Processor: AMD Ryzen™ 7 1700 8-core/16-thread 3.0 GHz processor, Turbo Core 3.7 GHz
Architecture: 64-bit
Graphics: Optional (with PCIe expansion card)
Encryption Engine: AES-NI |
| System Memory |
64 GB DDR4 (4 x 16 GB) |
| Maximum Memory |
64 GB (4 x 16 GB) |
| Memory Slot |
4 x UDIMM DDR4
(For dual- or quad-DIMM configurations, you must use a pair of identical DDR4 modules.) |
| Flash Memory |
512MB DOM |
| Drive Bay |
8 x 3.5-inch SATA 6 Gbps bays
4 x 2.5-inch SATA 6 Gbps bays |
| Drive Compatibility |
3.5-inch bays:
• 3.5-inch SATA hard disk drives
• 2.5-inch SATA hard disk drives
• 2.5-inch SATA solid state drives
2.5-inch bays:
• 2.5-inch solid state drives |
| M.2 SSD Slot |
2 x M.2 2240/2260/2280/22110 SATA 6Gb/s SSDs
Note:
1. The M.2 SSD is not included as standard.
2. M.2 SSD operations can easily generate excessive heat. It is recommended to install a heatsink (from QNAP or a third-party provider) on the M.2 SSD. |
| SSD Cache Acceleration Support |
• 3.5-inch drive bays 1 to 8
• 2.5-inch drive bays 1 to 4
• M.2 slots 1 to 2
• Optional: SSD using PCIe expansion slot |
| Hot-swappable |
Yes
The following are not hot-swappable: M.2 SSDs, SSD cache drives, SSDs using PCIe expansion slots. |
| 10 Gigabit Ethernet Port |
Optional: With PCIe expansion card |
| Gigabit Ethernet Port |
4 x RJ45 |
| PCIe Slot |
1 x PCIe 3.0 x8
1 x PCIe 3.0 x4
1 x PCIe 2.0 x4 |
| USB Port |
2 x USB 3.1 10 Gbps
• Back: 1 x USB 3.1 10 Gbps Type-C
• Back: 1 x USB 3.1 10 Gbps Type-A
6 x USB 3.0
• Front: 1 x USB 3.0 Type-A (Note: It comes with the One-Touch Copy button)
• Back: 5 x USB 3.0 Type-A |
| HDMI Output |
Optional: With PCIe expansion card |
| Audio |
• 2 x 3.5 mm dynamic microphone jacks
• 1 x 3.5 mm line-out jack
• 2 x speakers
Note: You cannot use the speakers and the line-out jack simultaneously. |
| Display Panel |
Monochrome backlit LCD display with Enter and Select buttons |
| USB One Touch Copy |
Front: USB 3.0 Type-A |
| Form Factor |
Tower |
| Dimensions (H x W x D) |
234.6 x 369.9 x 319.8 mm
9.23 x 14.56 x 12.59 inch |
| Net Weight |
11.55 kg (25.46 lbs) |
| Power Supply Unit |
550W, 100-240V AC, 50/60Hz |
| Fan |
System: 3 x 80 mm
CPU: 2 x 90 mm |
| Operating Temperature & Relative Humidity |
0 ~ 40˚C ( 32˚F ~ 104˚F ), 5 ~ 95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Security Slot |
Kensington security slot |
