Emulex Контроллер OneConnect™ OCe11102-NX dual-port 10Gb/s Ethernet network adapter with copper interconnects

Controller

• BladeEngine® 3

Standards

• PCI Express base spec 2.0, PCI Bus Power Management Interface, rev. 1.2, Advanced Error Reporting (AER)
• IEEE 802.3ae (10Gb/s Ethernet)
• 802.1q(VLAN)
• 802.1p (QoS/CoS)
• 802.3ad (Link Aggregation)
• 802.3x (Flow Control)
• PHP hot plug-hot swap

Architecture

• Dual-port, 10Gb/s Ethernet Link speed
• PCIe Express 2.0 (x8, 5GT/s), MSI-X support
• Integrated data buffer and code space memory

Ethernet Features

• IPv4/IPv6 TCP, UDP checksum offload; Large Send Offload (LSO); Large Receive Offload; Receive Side Scaling (RSS); TCP Segmentation Offload (TSO); IPv4 TCP Chimney Offload
• VLAN insertion and extraction
• Jumbo frames up to 9000 Bytes
• Priority Flow Control for Ethernet traffic
• Preboot eXecution Environment (PXE) 2.0 network boot support
• Interrupt coalescing
• Load balancing and failover support including adapter fault tolerance (AFT), switch fault tolerance (SFT), adaptive load balancing (ALB), teaming support, VMW NetQueue v2 and IEEE 802.3ad, VT-d / IOMMU support

I/O Virtualization

• PCI-SIG SR-IOV compliant
• On-chip VM to VM switching
• Quality of Service (QoS) across each Virtual and Physical Function

Comprehensive OS Support

• Windows Server
• VMware ESX
• Red Hat Enterprise Linux Server
• Novell SUSE® Linux Enterprise Server
• Oracle Solaris
• CentOS
• Ubuntu
• FreeBSD
• View OS versions and available drivers

Hardware Environments

• x86, x64 and PPC processor families

Interconnect

• Copper Direct Attach
  • SFP+ Direct Attach Twin-Ax Copper interface
  • Standards compliant passive copper cables up to 5m, active copper cables up to 10m
• Optical
  • Optics: 10GBASE-SR short wave lasers with LC type connector

Physical Dimensions

• Short, low-profile form factor card
• 167.64mm x 68.91mm (6.60” x 2.71”)
• Standard bracket (low profile available)

Environmental Requirements

• Operating temperature: 0° to 55° C (32° to 131° F)
• Storage temperature: -40° to 70° C (-40° to 158° F)
• Relative humidity: 5% to 95% non-condensing
