| CPU | Dual-core Intel® 2.4 GHz Processor |
| DRAM | 4 GB DDR3 RAM
NOTE:
1.The system memory can be increased to 16GB by installing three additional 4GB Long-DIMM RAM modules.
|
| Flash Memory | 512MB DOM |
| Hard Drive | 8x 3.5” or 2.5” SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
NOTE:
1. The standard system is shipped without hard drives.
|
| Hard Drive Tray | 8 x hot-swappable and lockable tray |
| LAN Port | 2 x Gigabit RJ-45 Ethernet port
(Expandable up to 6 x 1 Gb LAN or 4 x 10 Gb + 2 x 1 Gb LAN by installing optional dual-port 10 Gb and 1 Gb network card)
Note:
1. For the optional network card compatibility list, please visit //www.qnap.com/en/index.php?lang=en&sn=4061
2. For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual. |
| LED Indicators | Status, 10 GbE, LAN, eSATA, hard drives |
| USB | 2x USB 3.0 port (rear)
4x USB 2.0 port (rear)
Support USB printer, pen drive, USB hub, and USB UPS etc. |
| eSATA | 2 (rear) |
| Buttons | System: Power button and reset button |
| Alarm Buzzer | System warning |
| Form Factor | 2U, Rackmount |
| Dimensions | 89 (H) x 482 (W) x 534 (D) mm
3.50 (H) x 18.98 (W) x 21.02 (D) inch |
| Weight | 9.9 kg/21.83 lb (Net)
12.74 kg/ 28.09 lb (Gross) |
| Sound Level (dB) | Standby: 45.8 dB
In operation: 47.5 dB
(with 8 x Hitachi HUA723020ALA640 MK7O installed) |
| Power Consumption (W) | Sleep mode: 74.7 W
In Operation: 155.2 W
(with 8 x Hitachi HUA723020ALA640 hard drive installed) |
| Temperature | 0-40˚C |
| Relative Humidity | 0~90% |
| Power Supply | Input: 100-240V AC, 47-63Hz
Output: 300W |
| Expansion Slot | 2 (for network and storage expansion) |
| Fan | 2 x quiet cooling fan (7 cm, 12V DC) |
