| CPU |
AnnapurnaLabs, an Amazon company Alpine AL-324 Quad-core 1.7GHz ARM® Cortex-A57 Processor, 64-bit |
| Encryption Acceleration |
|
| System Memory |
4 GB DDR4 2400 (1 x 4 GB) |
| Maximum Memory |
16 GB (1 x 16 GB) |
| Memory Slot |
1 x SODIMM slot |
| Flash Memory |
512 MB NAND Flash |
| Drive Bay |
Hot-swappable 3 x 3.5"/2.5" SATA 6Gb/s HDD/SSDs (2.5" tray base for installing 2.5" HDD/SSD can be purchased from QNAP Online Shop) |
| M.2 SSD Slot |
3 x M.2 2280 SATA 6 Gbps SSD
Note:
1. The M.2 SSD is not included as standard.
2. M.2 SSD operations can easily generate excessive heat. It is recommended to install a heatsink (from QNAP or a third-party provider) on the M.2 SSD. |
| 10 Gigabit Ethernet Port |
1 x 10GbE SFP+ |
| Gigabit Ethernet Port |
2 x Gigabit RJ45 |
| USB Port |
USB 3.0 (Front: 1; Rear: 2) |
| Audio |
1 x Built-in speaker
1 x 3.5mm line out jack
Note: You cannot use the speakers and the line-out jack simultaneously. |
| LED Indicators |
Status/Power, LAN, USB, HDD 1-3, M.2 SSD 1-3 |
| Buttons |
Power, Reset, USB One-touch-copy |
| System Warning |
Buzzer or Smart voice prompt |
| Form Factor |
Tower |
| Dimensions (H x W x D) |
142 x 150 x 260.1 mm
5.59 x 5.9 x 10.24 inch |
| Power Consumption (W) |
HDD standby: 18.56 W
In operation: 26.22 W
(with 3 x HDDs and 3 x M.2 SSDs)
HDD:WD10EFRX
M.2 SSD: RBU-SNS8152S3256GG2 256G |
| Sound Level |
Sound pressure (LpAm): 20.4 dB(A) |
| Weight |
Net weight: 1.64 kg (3.62 lbs)
Gross Weight: 2.69 kg (5.93 lbs) |
| Operating Temperature & Relative Humidity |
0 ~ 40˚C (32˚F ~ 104˚F)
5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Security Slot |
Kensington security slot |
| Fan |
1 x 14cm smart fan (12V DC) |
| Power Supply Unit |
90W AC external adapter, 100-240V |
