| Model Name |
TDS-16489U-SA1
(E5-2620 2.4GHz 6-core processor x2, 64GB DDR4 RDIMM)
TDS-16489U-SB2
(E5-2630 2.4GHz 8-core processor x2, 128GB DDR4 RDIMM) |
TDS-16489U-SA2
(E5-2620 2.4GHz 6-core processor x2, 128GB DDR4 RDIMM)
TDS-16489U-SB3
(E5-2630 2.4GHz 8-core processor x2, 256GB DDR4 RDIMM) |
| CPU |
Intel® Xeon® E5-2600 v3 Family processor
- Intel® Xeon® 4-core Processor E5-2623 v3 (10M Cache, 3.00 GHz, 4-core)*
- Intel® Xeon® 6-core Processor E5-2620 v3 (15M Cache, 2.40 GHz)
- Intel® Xeon® 8-core Processor E5-2630 v3 (20M Cache, 2.40 GHz)
- Intel® Xeon® 8-core Processor E5-2640 v3 (20M Cache, 2.60 GHz)*
*Available with customization requirement
|
| Memory |
System memory: RDIMM / LRDIMM
Total memory slots:16
Naming rule:
|
| USB |
4 x USB 3.0 port |
| Hard Drive |
- 16 x 3.5-inch SAS (12Gbps/6Gbps), SATA (6Gbps/3Gbps) hard drive, or 2.5-inch SAS/SATA SSD
- 4 x 2.5-inch SAS (12Gbps) SSD, or SAS/SATA (6Gbps/3Gbps) SSD
|
| Maximized Raw Capacity |
128 TB |
| Hard Drive Interface |
SAS 12Gb/s, backward compatible with SAS/SATA 6Gbps |
| 10/100/1000 Mbps LAN Port |
2 |
| 10Gbps LAN Port |
4 x SFP+、Intel XL710 |
| PCIe Slot |
4 (3 x PCIe Gen3 x8, 1 x PCIE Gen3 x16) |
| Form Factor |
3U, rackmount |
| Dimension |
130.8 (H) x 444 (W) x 744 (D) mm |
| Weight |
Net weight (NAS only): 22.42 kg/ 49.43 lb
Gross weight (with packing and accessories): 30.19 kg/ 66.56 lb |
| Sound Level* |
Sound pressure (LpAm) :37.8 dB(A) |
| Power Consumption |
Sleep mode: 254.21 W
In Operation: 362.86 W |
| Power Supply |
650W (Redundant power) |
| Fan |
4 x 6cm smart cooling fan (12V DC) |
| 1. |
Power Button |
7. |
IPMI VGA |
| 2. |
LED Indicator:
10 GbE, Status, LAN, Storage Expansion Port Status |
8. |
IPMI Console |
| 3. |
10 GbE SFP+ Port x 4 |
9. |
Gigabit LAN Port x 2 |
| 4. |
Password & Network Settings Reset Button |
10. |
USB Port x 4 |
| 5. |
Console (Reserved) |
11. |
PCIe Slot x 4
(Left slot: 3 x PCIe Gen3 x8; Left slot: 1 x PCIe Gen3 x16) |
| 6. |
IPMI LAN Port |
12. |
Power Connector |
Remark:
The TDS-16489U rack mount models comply with ANSI/EIA-RS-310-D rack mounting standards. Before purchasing the server racks for these models, please make sure the server racks conform to the following criteria:
1. Rack size
- Mounting post width : ≥ 451mm
- Panel width : ≥ 485mm
- Mounting post depth : 579.1mm~873.5mm
- The distance between two rack posts is 465mm (center-to-center measurement of the rack's square holes)
2. The optional rack kits for the TDS-16489U rack mount models are only compatible with square-hole server racks.
* Tseting Environment:
Refer to ISO 7779, ISO 3744 ,Telcordia GR 63 CORE and ETSI EN 300 753 ; Maximum HDD loaded ; 40HL ½ " High Sensitivity
Microphone at the by stander position. ; Background noise is 6.5 ~ 7.0dB(A) ; Ambient temperature is 21 ± 2℃ ; Relative humidity is 63% ± 5%
Designs and specifications are subject to change without notice.
