| CPU |
AMD® x86 G-Series Quad-core 2.0 GHz processor |
|
Floating Point Unit
|
Yes |
|
Hardware Encryption Engine
|
Yes (AES-NI) |
| DRAM |
System memory:
TS-563-2G: 2GB DDR3 RAM (2GB x1)
TS-563-8G: 8GB DDR3 RAM (8GB x1)
Total memory slots: 2 SODIMM
Memory expandable up to: 16 GB (8GB x 2)
NOTE:
1. When installing two memory modules, please ensure that they are the same size and ideally use the same type of RAM for both memory slots.
2. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide |
| Flash Memory |
512MB |
| Hard Disk Drive |
5 x 3.5"or 2.5"SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
NOTE:
1. The system is shipped without HDD.
2. For the HDD compatibility list, please visit https://www.qnap.com/compatibility |
| Hard Disk Tray |
5 x Hot-swappable tray |
| LAN Port |
2 x Gigabit RJ-45 Ethernet port (Expandable up to 4 x GbE or 2 x 10GbE + 2 x GbE via PCIe NIC) |
| Network Expansion Slot |
1 (PCIe Gen2 x 4) |
| LED Indicators |
Status, USB, HDD 1-5 |
| USB |
5 x USB 3.0 port (Front: 1, Rear: 4)
Support USB printer, pen drive, and USB UPS etc. |
| Buttons |
Power/Status, USB One-Touch-Backup, reset |
| Alarm Buzzer |
System warning |
| Form Factor |
Tower |
| Dimensions |
185(H) x 210.6(W) x 235.4(D) mm
7.28(H) x 8.29(W) x 9.27(D) inch |
| Weight |
Net: 4.4 kg (9.7 lbs)
Gross: 5.8 kg (12.79 lbs) |
| Power Consumption (W) |
S3 sleep: 2.26W
HDD standby: 30.17W
In operation: 47.68W
(with 5 x 2TB HDDs installed) |
| Temperature |
0-40˚C |
| Humidity |
5~95% RH non-condensing, wet bulb: 27˚C |
| Power Supply |
ATX 250W, 110-240V AC, 50-60Hz, 5A |
| Secure Design |
Kensington security slot for theft prevention |
| Fan |
1 x quiet cooling fan (12cm, 12V DC) |
