Emulex LP1050DC-F2

Цена: 127160 р
Наличие: Под заказ
Производитель:EMULEX
Emulex LP1050DC-F2

Emulex LP1050DC-F2

Особенности
  • Low-cost HBAs optimized for today's most popular OS SAN environments
  • Single- and dual-channel models available
  • PCI-X to 2Gb/s Fibre Channel delivering up to 400MB/s (per channel)
  • Full fabric support with automatic topology and speed adaption
  • cHBA API support (FC-MI) enables simplified SAN management
  • Onboard hardware context cache for superior fabric support and high transaction performance
  • Support for use of multiple concurrent protocols (SCSI and IP)
  • Full service class 2 and 3 support
  • Simultaneous on card support for remote boot support in x86 and Itanium (BootBIOS and EFI) environments
  • End-to-end parity protection for high data integrity
Технические характеристики
Controller Type Fibre Channel Controller
Enclosure Internal
Platform PC • Unix
Bus Type PCI-X
Data Transfer Rate 2000 MBps
Number of Internal Connectors 2
MPN lp1050dc-f2
Ports channels 2, LC short-wave optical Port(s)
Host Interface PCI-x 133MHZPCI-x 100MHZPCI-x 66MHz
Backward compatibility PCI 66MHz 64-bitpci 32MHZ 32-bit
Topology Point-To-pointarbitrated loopswitched fabric
Supported fibre channel class Class 2CLASS 3
Connectivity Media 50/125, M Multi-mode Fiber fibre CHANNEL62.5/125, M Multi-mode Fiber fibre channel
Data transfer rate 1.0625GBPS fibre CHANNEL2.125GBPS fibre channel
Data throughput 400 Mbps per channel fibre channel
Supported distance 984 Ft 50/125, M Multi-mode Fiber, @ 2 GBPS492, Ft 62.5/125, M Multi-mode Fiber, @ 2 GBPS
Protocols FC-FSFC-PHFC-pifc-FCP2FC-FCPFC-alfc-pldafc-mifc-flascsitcp Ip
Input Voltage 3.3 V DC5 V DC
Power Consumption 8.1 w typical @ 66 MHZ11.6 w maximum @ 66 MHZ9.2 w typical @ 100 MHZ13.1 w maximum @ 100 MHZ9.2 w typical @ 133 MHZ13.1 w maximum @ 133 MHz
Temperature 0, C (32, F) to 45, C (113, F) operating-40, C (-40 F) to 70, C (158, F) Storage
Humidity 5% to 95% non-condensing relative Humidity
Form factor Low-profile MD2 hot-swappable
Dimensions 6.60, x 2.54
Additional information Quad data rate (QDR) SRAM unified data buffer & code space memory 16 buffer-To-buffer credits supported (per channel) 1K+ contexts cached onboard (per channel) 3.3V signaling, 5V tolerant Standard bracket (low profile available) airflow required: 100 LF/M automatic topology and speed adaption onboard Hardware context cache for Superior fabric support and High, transaction performance support for Use of multiple concurrent Protocols (SCSI & Ip) simultaneous on card support for remote boot support in X86 and itanium (bootbios and efi) environments end-To-end parity protection for High data integrity 1GIG/2GIG serdes Compatibility: operating system: Windows server 2003 Windows 2000 Windows NT NetWare Linux Hardware: X86 Intel itanium processor family Certifications & Standards: IETF Ip over FC PCI-x 1.0A PCI 2.3 agency approvals: Class 1 Laser Product per DHHS 21CFR (J) & EN60825 UL recognized to UL 1950 cur recognized to CSA22.2, No. 950 TUV certified to EN60950 FCC rules, Part 15, class a ices-003: Class a EMC directive 89/336/EEC (CE MARK) EN55022, class a EN55024 australian EMC framework (C-tick MARK) as/NZS: 3548, class a VCCI: Class a MIC (Korea): Class a bsmi (Taiwan): Class a
Standard Warranty 3 Year(s)
