| Hardware Specifications |
| CPU |
| CPU Model |
Intel Celeron N3150 |
| CPU Architecture |
64-bit |
| CPU Frequency |
Quad Core 1.6 burst to 2.08 GHz |
| Floating Point |
|
| Hardware Encryption Engine (AES-NI) |
|
| Hardware Transcoding Engine |
H.264 (AVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30 |
| Memory |
| System Memory |
2 GB DDR3 |
| Storage |
| Drive Bay(s) |
2 |
| Maximum Drive Bays with Expansion Unit |
7 |
| Compatible Drive Type (See all supported drives) |
- 3.5" SATA III / SATA II HDD
- 2.5" SATA III / SATA II HDD
- 2.5" SATA III / SATA II SSD
|
| Maximum Internal Raw Capacity |
16 TB (8 TB HDD X 2) (Capacity may vary by RAID types) |
| Maximum Raw Capacity with Expansion Units |
56 TB (8 TB HDD X 7) (Capacity may vary by RAID types) |
| Maximum Single Volume Size |
108 TB |
| Hot Swappable Drive |
|
| External Ports |
| USB 3.0 Port |
3 |
| eSATA Port |
1 |
| USBCopy |
|
| File System |
| Internal Drives |
|
| External Drives |
- Btrfs
- EXT4
- EXT3
- FAT
- NTFS
- HFS+
|
| Appearance |
| Size (Height X Width X Depth) |
157 mm X 103.5 mm X 232 mm |
| Weight |
1.75 kg |
| Others |
| RJ-45 1GbE LAN Port |
2 (with Link Aggregation / Failover support) |
| Wake on LAN/WAN |
|
| System Fan |
92 mm X 92 mm X 1 pcs |
| Fan Speed Mode |
|
| Wireless Support (dongle) |
|
| Power Recovery |
|
| Noise Level* |
18 dB(A) |
| Scheduled Power On/Off |
|
| Power Supply Unit / Adapter |
65W |
| AC Input Power Voltage |
100V to 240V AC |
| Power Frequency |
50/60 Hz, Single Phase |
| Power Consumption* |
25.84 W (Access)
8.84 W (HDD Hibernation) |
| British Thermal Unit |
88.23 BTU/hr (Access)
30.18 BTU/hr (HDD Hibernation) |
| Environment Temperature |
| Operating Temperature |
5°C to 40°C (40°F to 104°F) |
| Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
| Relative Humidity |
5% to 95% RH |
| Certification |
- FCC Class B
- CE Class B
- BSMI Class B
|
| Warranty |
3 Years |
| Notes |
- Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
- Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
|
| DSM Specifications ( See more ) |
| Storage Management |
| Maximum Internal Volume Number |
512 |
| Maximum iSCSI Target Number |
32 |
| Maximum iSCSI LUN |
256 |
| iSCSI LUN Clone/Snapshot, Windows ODX |
|
| Supported RAID Type |
- Synology Hybrid RAID
- Basic
- JBOD
- RAID 0
- RAID 1
- RAID 5 (with Expansion Unit)
- RAID 6 (with Expansion Unit)
- RAID 10 (with Expansion Unit)
|
| RAID Migration |
- Basic to RAID 1
- Basic to RAID 5 (with Expansion Unit)
- RAID 1 to RAID 5 (with Expansion Unit)
- RAID 5 to RAID 6 (with Expansion Unit)
|
| Volume Expansion with Larger HDDs |
- Synology Hybrid RAID
- RAID 1
- RAID 5 (with Expansion Unit)
- RAID 6 (with Expansion Unit)
|
| Volume Expansion by Adding a HDD |
- Synology Hybrid RAID
- RAID 5 (with Expansion Unit)
- RAID 6 (with Expansion Unit)
- JBOD (with Expansion Unit)
|
| Global Hot Spare Supported RAID Type |
- Synology Hybrid RAID (with Expansion Unit)
- RAID 1 (with Expansion Unit)
- RAID 5 (with Expansion Unit)
- RAID 6 (with Expansion Unit)
- RAID 10 (with Expansion Unit)
|
| SSD Support |
| SSD Read/Write Cache (White Paper) |
|
| File Sharing Capacity |
| Maximum User Accounts |
2048 |
| Maximum Groups |
256 |
| Maximum Shared Folder |
512 |
| Maximum Shared Folder Sync Tasks |
8 |
| Maximum Concurrent CIFS/AFP/FTP Connections |
512 |
| Windows Access Control List (ACL) Integration |
|
| NFS Kerberos Authentication |
|
| Data Protection Manager |
|
| Maximum Snapshots per Shared Folder |
64 |
| High Availability Manager |
|
| Log Center |
|
| Syslog Events per Second |
800 |
| Virtualization |
| VMware vSphere 5 with VAAI |
|
| Windows Server 2012 |
|
| Windows Server 2012 R2 |
|
| Citrix Ready |
|
| Add-on Packages (See more) |
| Antivirus Essential |
|
| Antivirus by McAfee (Trial) |
|
| Audio Station |
|
| Central Management System |
|
| Cloud Station |
|
| Maximum Concurrent File Transfers |
512 |
| Cloud Sync |
|
| Directory Server |
|
| DNS Server |
|
| Download Station |
|
| Maximum Concurrent Download Tasks |
80 |
| Glacier Backup |
|
| HiDrive Backup |
|
| iTunes Server |
|
| Java Manager |
|
| Mail Server |
|
| Mail Station |
|
| Media Server |
|
| DLNA Compliance |
|
| Note Station |
|
| Photo Station |
|
| RADIUS Server |
|
| Surveillance Station |
|
| Maximum IP cam (Licenses required) |
40 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264)* |
1200 FPS @ 720p (1280x720)
800 FPS @ 1080p (1920×1080)
300 FPS @ 3M (2048x1536)
250 FPS @ 5M (2591x1944) |
| Total FPS (MJPEG)* |
450 FPS @ 720p (1280x720)
150 FPS @ 1080p (1920×1080)
100 FPS @ 3M (2048x1536)
72 FPS @ 5M (2591x1944) |
| Video Station |
|
| Video Transcoding |
4K Group 1 (See more) |
| VPN Server |
|
| Maximum Connections |
20 |
| Notes |
Surveillance Station throughput is tested with Axis P1347 (H.264@1280x720@30FPS), using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. Recording video is saved every 5 minutes with the limit of archive folder up to 1GB. |
| Environment & Packaging |
| Environment |
RoHS Compliant |
| Packaging Content |
- Main Unit X 1
- Welcome Note X 1
- Accessory Pack X 1
- AC Power Adapter X 1
- AC Power Cord X 1
- RJ-45 LAN Cable X 2
|
| Optional Accessories |
- Camera License Pack
- EXpansion Unit: DX213 X 1
- EXpansion Unit: DX513 X 1
- VS360HD
|
