| Ordering P/N |
TS-431XeU-2G |
TS-431XeU-8G |
| Processor |
AnnapurnaLabs, an Amazon company, Alpine AL-314 Quad-Core 1.7 GHz |
|
Hardware Encryption Accleration
|
Yes |
| System Memory |
1 x 2GB SO DIMM DDR3-1600 |
1 x 8GB SO DIMM DDR3-1600 |
| Maximum Memory |
1 x 8GB SO DIMM DDR3-1600 |
| Memory Slots |
1 |
| Hard Drive Tray |
4 |
| Drive Interface |
SATA 6 Gb/s, HDD or SSD |
| Drive Type |
3.5-inch or 2.5-inch |
| 10GbE LAN |
1 x 10 Gigabit SFP+ port |
| GbE LAN |
2 x Gigabit RJ45 LAN port |
| USB |
4 x USB 3.0 |
| Storage expansion |
- 1x UX-800U-RP and 1x UX-1200U-RP
- 2x UX-800U-RP
- 1x UX-800U-RP or UX-1200U-RP
Up to 24 drives are supported. |
| Fan |
3 x 4 cm system fan (12V DC) |
| Power Supply |
100W, 100-240V AC, 50/60Hz, open frame |
| LED Indicators |
HDD1, HDD2, HDD3, HDD4, LAN1, LAN2, 10GbE, STATUS |
| Buttons |
Power, Reset |
| Other I/O |
Kensington security slot, console port |
| System Warning |
Buzzer |
| Form Factor |
1U |
| Dimension (H x W x D) |
44 x 439 x 291 mm |
| Weight |
4.15 kg (net); 5.78 kg (gross) |
| Operating Temperature |
0 to 40 degree of Celsius |
| Relative Humidity |
5 to 95 % non-condensing, wet bulb: 27 degree of Celsius |
| Noise Level; Sound Level (dB)* |
20.3 |
| Power Consumption |
HDD standby: 12.42
In operation: 30.99
(With 4 x2TB HDDs installed) |
