| Ordering P/N |
TBS-453A-4G-960GB |
TBS-453A-4G-480GB |
TBS-453A-4G |
TBS-453A-8G-960GB |
TBS-453A-8G-480GB |
TBS-453A-8G |
| Processor |
14nm Intel® Celeron® N3150 quad-core 1.6GHz, burst up to 2.08GHz |
|
Floating Point Unit
|
✔ |
|
Hardware Encryption Acceleration
|
✔ (AES-NI) |
| GPU |
8th generation Intel HD Graphics |
| System Memory |
4GB (2 x 2GB) |
8GB (2 x 4GB) |
| Maximum Memory |
8GB |
| Memory Slot |
2, SODIMM DDR3L-1600 (*For dual-DIMM configurations, you must use a pair of identical DDR3L RAM modules.) |
| Flash |
4GB |
| Drive Type |
4 x M.2 2280/2260/2242 SATA 6Gb/s SSDs |
| Pre-installed M.2 SSDs |
4 x 240GB* |
2 x 240GB* |
- |
4 x 240GB* |
2 x 240GB* |
- |
| Raw Capacity |
960GB (RAID 0) |
480GB (RAID 0) |
Optional purchase |
960GB (RAID 0) |
480GB (RAID 0) |
Optional purchase |
| Default Capacity (Factory Configuration) |
720GB (RAID 5) |
240GB (RAID 1) |
Optional purchase |
720GB (RAID 5) |
240GB (RAID 1) |
Optional purchase |
| Network |
2 x Gigabit LAN ports & 3 x Gigabit switch ports (LAN port 2-1, 2-2, 2-3, 2-4 are designed as switch ports) |
| USB Port |
4 x USB 3.0 & 1 x USB 2.0 ports
Support USB printer, pen drive, and USB UPS, etc. |
| Video Output |
2 x HDMI, up to 4K 2160P Ultra HD support |
| Audio Input |
2 x 3.5mm microphone jack (dynamic microphone only) |
| Audio Output |
1 x built-in speaker, 1 x line out jack (for amplifier or headphone amplifier) |
| LED |
Status/Power, USB, SSD 1-4 |
| Button |
Power, USB one-touch-backup, Reset, Volume Up, Volume Down |
| IR Receiver |
✔, support QNAP RM-IR002, RM-IR003 and MCE-compatible Remote Control(DM) |
| Security |
Kensington security slot |
| Dimension (HxWxD) |
25 x 230 x 165 mm / 0.98 x 9.06 x 6.50 inch |
| Weight |
760g / 1.68lbs. |
742g / 1.64lbs. |
724g / 1.60lbs. |
760g / 1.68lbs. |
742g / 1.64lbs. |
724g / 1.60lbs. |
| Power Consumption (W) |
System sleep mode: 0.98W
SSD standby: 13.05W
In operation: 15.2W |
| Sound Level** |
Sound pressure (LpAm) :10.8 dB(A) |
| Working Temperature |
0-40˚C |
| Relative Humidity |
5~95% RH non-condensing, wet bulb: 27˚C |
| Power |
DC10V-20V wide input range |
| Fan |
Compact internal fan |
| Package Contents |
NASbook, 65W 19V AC adapter, power cord, quick installation guide, Ethernet cable x 2, remote control, SSD installation kit |
