| CPU |
AMD R-Series RX-421BD quad-core 2.1 GHz processor, burst up to 3.4 GHz |
|
Hardware Encryption Accleration
|
Yes, AES-NI |
|
Graphics
|
Embedded Radeon™ R7 Graphics Processor |
| System Memory |
TVS-473-64G: 64GB DDR4 (4 x 16GB)
TVS-473-16G: 16GB DDR4 (2 x 8GB)
TVS-473-8G: 8GB DDR4 (2 x 4GB) |
| Maximum Memory |
64GB |
| Memory Slot |
4 x SODIMM DDR4
(For dual- or quad-DIMM configurations, you must use a pair of identical DDR4 modules.) |
| Flash Memory |
512MB DOM |
| Hard Disk Drive |
4 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs |
| M.2 SSD Slot |
2 x 2280/2260 SATA 6Gb/s |
| LAN Port |
4 x Gigabit RJ45 LAN ports |
| PCIe Slot |
2 x PCIe Gen 3 (x4), one slot is pre-installed with a dual-port USB 3.1 Type-A card |
| LCD Panel |
Mono-LCD display with backlight, Enter and Select buttons for configuration |
| USB |
2 x USB 3.1 port, and 4 x USB 3.0 Type-A port |
| HDMI |
2, up to 3840 x 2160 @ 30Hz resolution |
| LED Indicator |
Status/Power, USB, LAN, Drive 1-4, M.2 SSD 1-2 |
| Button |
Power/Status, USB one-touch-backup, Reset |
| IR Receiver |
Yes, support QNAP RM-IR004 and MCE-compatible remotes |
| Others |
Kensington security slot, system maintenance port |
| Form Factor |
Tower |
| Dimension (H x W x D) |
188.2 x 199.3 x 279.6 mm
7.41 x 7.85 x 11.01 inch |
| Weight |
4.9 kg / 10.80 lbs |
| Operating Temperature |
0 ~ 40˚C |
| Relative Humidity |
5~95% RH non-condensing, wet bulb: 27˚C |
| Power |
ATX 240W, 100-240V AC, 50-60Hz, 3.5A |
| Fan |
1 x 12cm |
