| Ordering P/N |
TS-531X-2G |
TS-531X-8G |
| Processor |
AnnapurnaLabs, an Amazon company Alpine AL-314 Quad-core 1.4GHz ARM® Cortex-A15 Processor |
|
Hardware Encryption Accleration
|
✔ |
| System Memory |
2GB DDR3 (1 x 2GB) |
8GB DDR3 (1 x 8GB) |
| Maximum Memory |
16GB |
| Memory Slots |
2 x SODIMM DDR3 (Note: For dual-DIMM configurations, you must use a pair of identical DDR3 RAM modules.) |
| Flash Memory |
512MB |
| Drive Type |
5 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs |
| 10GbE LAN |
2 x 10 Gigabit SFP+ LAN Ports |
| GbE LAN |
2 x Gigabit RJ45 LAN Ports |
| USB |
3 x USB 3.0 ports |
| PCIe Slot |
1 x PCIe Gen2 (x2) |
| LED |
Status/Power, LAN, USB, HDD 1-5 |
| Button |
Power, USB One-touch-copy，Reset |
| Other |
Kensington security slot，console port |
| Dimension |
185 (H) x 210.6 (W) x 235.4 (D) mm
7.28 (H) x 8.29 (W) x 9.27 (D) inch |
| Weight |
Net：5.8 kg (12.79 lbs) |
Net：5.9 kg ( 13 lbs) |
| Operating Temperature |
0-40˚C |
| Relative Humidity |
5~95% RH non-condensing, wet bulb: 27˚C |
| Noise Level |
22.4 dB(A)
Refer to ISO 7779 ; Maximum HDD loaded ; Bystander Position ; Average data from 1 meter in front of operating NAS |
| Power Consumption |
HDD standby: 17.01W
In operation: 29.31W
(with 5 x 1TB HDDs installed) |
| Power |
ATX 240W, 100-240V AC, 50-60Hz, 3.5A |
| Fan |
1 x 12cm fan (12V DC) |
