| Ordering P/N |
TS-431XU-RP-2G |
| Processor |
AnnapurnaLabs, an Amazon company Alpine AL-314 Quad-Core 1.7 GHz ARM® Cortex-A15 CPU |
|
Hardware Encryption Accleration
|
✔ |
| System Memory |
2GB DDR3 (1 x 2GB) |
| Maximum Memory |
16GB |
| Memory Slots |
2 x SODIMM DDR3
(Note: For dual-DIMM configurations, you must use a pair of identical DDR3 RAM modules.) |
| Flash Memory |
512MB |
| Drive Type |
4 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs |
| 10GbE LAN |
2 x 10 Gigabit SFP+ LAN ports |
| GbE LAN |
2 x Gigabit RJ45 LAN ports |
| USB |
4 x USB 3.0 ports |
| PCIe Slot |
1 x PCIe Gen2 (x2) |
| LED |
Status/Power, LAN, HDD 1-4 |
| Button |
Power, Reset |
| Other |
Kensington security slot, console port |
| Dimension (HxWxD) |
44 x 439 x 499 mm
1.73 x 17.28 x 19.65 inch |
| Weight |
Net: 9.12 kg (20.11 lbs)
Gross: 11.10 kg (24.47 lbs) |
| Operating Temperature |
0-40˚C |
| Relative Humidity |
5~95% RH non-condensing, wet bulb: 27˚C |
| Noise Level |
38.3 dB(A)* |
| Power Consumption |
HDD standby: 36.05W
In operation: 51.16W
(with 4 x 2TB HDDs installed) |
| Power |
ATX 250W, 100-240V AC, 5A-2.5A, 50Hz-60Hz (x2) |
| Fan |
2 x 4cm system fan (12V DC) |
