| Host Interface |
Three SAS 6Gbps 4x wide port (SFF-8644) |
| Drive Bay |
12 x 3.5-inch SATA 6Gb/s, 3Gb/s hard drive or 2.5-inch SATA SSD |
| LED Indicators |
Front panel: Status, fault, system over heat, fan error
Rear panel: SAS link, SAS error, enclosure ID |
| Form Factor |
2U rackmount |
| Dimensions (H x W x D) |
88 x 439 x 520 mm
3.46 x 17.28 x 20.47 inch |
| Weight |
Net weight (NAS only): 14.8 kg/ 32.63 lb
Gross weight (with packing and accessories):21.99 kg/ 48.48 lb |
| Sound Level |
Sound pressure (LpAm): 46.1 dB(A) |
| Operating Temperature & Relative Humidity |
0 ~ 40˚C ( 32˚F ~ 104˚F ), 5 ~ 95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Consumption (W) |
In Operation 162.47 W |
| Power Supply Unit |
Redundant/Hot Swap ATX Power Supply, 400 W, 90-264 Vac~, 47-63 Hz |
| Fan |
3 x 6 cm smart cooling fan (hot-swappable fan module) |
